GIGABYTE MOTHERBOARD MATX ULTRA DURABLE B550M DS3H AC R2 DDR4 AM4 /AMD 3Y

Deskripsi

SPESIFIKASI

Brand: GIGABYTE

Tipe: B550M DS3H AC R2 Ultra Durable Motherboard

Socket: AM4

Form Factor: Micro ATX

Chipset: AMD B550

CPU Support:

AMD Ryzen 5000 G-Series Processors

AMD Ryzen 5000 Series Processors

AMD Ryzen 4000 G-Series Processors

AMD Ryzen 3000 G-Series Processors

AMD Ryzen 3000 Series Processors

Memory:

4 x DDR4 DIMM Slots

Max Capacity: 128 GB

Memory Speed Support: DDR4 4733(O.C.) 4600(O.C.) 4400(O.C.) 4266(O.C.) 4133(O.C.) 4000(O.C.) 3866(O.C.) 3733(O.C.) 3600(O.C.) 3466(O.C.) 3400(O.C.) 3200 2933 2667 2400 2133

Dual Channel Memory Architecture

Support for XMP Memory Modules

Graphics Output:

1 x DisplayPort Max Resolution 5120 x 2880 @ 60Hz

1 x HDMI Port Max Resolution 4096 x 2160 @ 60Hz

Audio:

Realtek ALC1220 Codec

High Definition Audio

2 4 5.1 7.1 Channel

LAN:

Realtek GbE LAN

Wireless:

Realtek WiFi RTL8821CE

WiFi 802.11 a b g n ac Dual Band 2.4GHz 5GHz

Bluetooth 5.0

Expansion Slots:

1 x PCIe 4.0 x16 Slot

1 x PCIe 3.0 x16 Slot Running at x4

1 x PCIe 3.0 x1 Slot

Storage:

2 x M.2 Socket 3 Connectors

4 x SATA 6Gb/s Ports

RAID 0 RAID 1 RAID 10 Support

USB:

4 x USB 3.2 Gen 1 Ports

1 x USB Type C with USB 3.2 Gen 1 Support

4 x USB 2.0 Ports

Back Panel I/O:

2 x USB 2.0 Ports

4 x USB 3.2 Gen 1 Ports

1 x PS/2 Port

1 x HDMI Port

1 x DisplayPort

1 x RJ45 LAN Port

2 x Antenna Connectors

3 x Audio Jacks

Operating System:

Windows 11 64-bit

Windows 10 64-bit

Dimension:

24.4 x 24.4 cm
