INTEL PROCESSOR ULTRA 9 285K LGA1851 3Y

Deskripsi

INTEL PROCESSOR ULTRA 9 285K LGA1851 3Y

Processor Intel Core Ultra 9 285K Box Arrow Lake Socket LGA 1851

Garansi Resmi 3 Tahun

CPU Specifications

- Total Cores: 24 (8 Performance-cores, 16 Efficient-cores)

- Threads: 24

- Max Turbo Frequency: 5.7 GHz

- Intel® Thermal Velocity Boost Frequency: 5.7 GHz

- Intel® Turbo Boost Max Technology 3.0 Frequency: 5.6 GHz

- Performance-core Max Turbo Frequency: 5.5 GHz

- Efficient-core Max Turbo Frequency: 4.6 GHz

- Performance-core Base Frequency: 3.7 GHz

- Efficient-core Base Frequency: 3.2 GHz

- Cache: 36 MB Intel® Smart Cache, 40 MB Total L2 Cache

- Processor Base Power: 125 W

- Maximum Turbo Power: 250 W

- AI Capabilities: Intel® Deep Learning Boost, with supported frameworks OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

- CPU Lithography: TSMC N3B

Supplemental Information

- Marketing Status: Launched (Q4 2024)

- Embedded Options: No

- Use Conditions: PC/Client/Tablet, Workstation

Memory Specifications

- Max Memory Size: 192 GB

- Memory Types: DDR5 up to 6400 MT/s

- Max Memory Speed: 6400 MHz

- Memory Channels: 2

- ECC Memory Supported: Yes

GPU Specifications

- GPU: Intel® Graphics

- Graphics Base Frequency: 300 MHz

- Graphics Max Dynamic Frequency: 2 GHz

- GPU Peak Performance: 8 TOPS (Int8)

- Graphics Output: DP2.1 UHBR20, HDMI2.1 FRL 12GHz, eDP1.4b

- Xe-cores: 4

- Max Resolution (HDMI): 4K @ 60Hz (HDMI 2.1 TMDS), 8K @ 60Hz (HDMI 2.1 FRL)

- Max Resolution (DP): 8K @ 60Hz

- Max Resolution (eDP): 4K @ 60Hz

- DirectX Support: 12

- OpenGL Support: 4.5

- OpenCL Support: 3

- Intel® Quick Sync Video: Yes

- Displays Supported: 4

- Device ID: 0x7D67

- AI Acceleration on GPU: Intel® Deep Learning Boost

NPU Specifications

- NPU: Intel® AI Boost

- Peak Performance: 13 TOPS (Int8)

- Sparsity Support: Yes

- Windows Studio Effects: Yes

- Supported AI Frameworks: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

- DMI Revision: 4

- DMI Lanes: 8

- Thunderbolt™ 4: Yes

- Scalability: 1S Only

- PCI Express Revision: 5.0 and 4.0, Configurations up to 1x16+2x4, 2x8+2x4, or 1x8+4x4

- Max PCI Express Lanes: 24
