MSI MOTHERBOARD MATX H510M PLUS II DDR4 LGA1200 /INTEL 3Y

Deskripsi

SPESIFIKASI

Brand: MSI

Model: Intel Z490 Series Motherboard

Color: Black

Chipset: Intel Z490

CPU Support:

Supports 10th Gen Intel® Core™ Processors

Supports 11th Gen Intel® Core™ Processors

Supports Intel® Pentium® Gold and Celeron® Processors

Memory:

2 x DDR4 DIMM slots

Maximum Capacity 64 GB

Memory Speed 2933 / 2666 / 2400 / 2133 MHz

Supports Dual Channel Memory Architecture

Supports non ECC Un-buffered Memory

Supports Intel® Extreme Memory Profile XMP

Graphics Output:

1 x HDMI supports up to 4K at 30Hz

1 x VGA supports up to 2048 x 1536 at 50Hz or 1920 x 1200 at 60Hz

Expansion Slots:

1 x PCIe 3.0 x16 slot

1 x PCIe 3.0 x1 slot

Storage:

1 x M.2 slot supports PCIe 3.0 x4 and SATA mode

Supports 2242 / 2260 / 2280 M.2 devices

4 x SATA 6Gb per second ports

Audio:

Realtek ALC897 7.1 Channel High Definition Audio

USB Ports:

Rear USB:

2 x USB 5Gbps Type-A

4 x USB 2.0

Front USB:

2 x USB 5Gbps Type-A

4 x USB 2.0

LAN: Realtek 8111H Gigabit Ethernet

Back Panel I O Ports:

HDMI

VGA

PS 2 Keyboard Mouse

USB 5Gbps Type-A

LAN Port

Audio Connectors

USB 2.0

Internal Connectors:

24-pin ATX Power Connector

CPU Power Connector

1 x CPU Fan Header

2 x System Fan Headers

Front Panel Connectors

Chassis Intrusion Header

Front Audio Header

COM Port Header

RGB LED Header

TPM Header supports TPM 2.0

Special Features:

EZ Debug LED

Operating System Support:

Windows 11 64-bit

Windows 10 64-bit
